Custom Optical Components | Precision Optics Manufacturer
Chenyu Optics manufactures custom optical components for laser, imaging, sensing and precision optical systems. Our product range includes optical windows, lenses, prisms, filters, mirrors, domes, rods and assembled optical components manufactured according to customer drawings. Capabilities include precision polishing, coating, mounting, bonding, alignment and inspection from prototype through OEM production.
Custom Optical Components Overview
Custom optical components are drawing-based precision optics manufactured with application-specific materials, geometries, surface quality, dimensional tolerances and optical coatings.
Chenyu Optics manufactures custom windows, lenses, prisms, filters, mirrors, domes and rods according to customer optical specifications. Where required, components can also be integrated with spacers, retaining rings, housings and custom mechanical parts.
Support includes prototype development, precision optical manufacturing, coating, component assembly, alignment, inspection and OEM production.
Custom Optical Component Types
Select a custom optical component or assembly category to review typical materials, functions and applications.
Custom Optical Windows
Precision windows manufactured to customer drawings, materials, dimensions and coating requirements.
Function: Optical Transmission and Environmental Protection
Applications: Imaging / Sensors / Laser Systems
Custom Optical Lenses
Spherical, aspheric and infrared lenses manufactured for precision imaging and beam control.
Function: Focusing, Collimation and Image Formation
Applications: Imaging / Laser Systems / Optical Instruments
Custom Optical Prisms
Drawing-based prism manufacturing with controlled geometry, angles, polishing and coatings.
Function: Beam Deviation, Image Orientation and Path Folding
Applications: Imaging / Measurement / Laser Systems
Custom Optical Filters
Custom spectral filters manufactured for wavelength selection, attenuation and optical protection.
Function: Spectral Selection, Attenuation and Wavelength Control
Applications: Machine Vision / Imaging / Spectroscopy
Custom Optical Mirrors
Flat and curved mirrors with metallic or dielectric coatings for precision reflective applications.
Function: Reflection, Beam Steering and Optical Path Control
Applications: Laser Systems / Imaging / Scientific Instruments
Custom Optical Domes
Hemispherical and custom-geometry domes for visible, infrared and multispectral protection.
Function: Optical Transmission and Sensor Protection
Applications: EO-IR Sensors / Thermal Imaging / Harsh Environments
Custom Optical Rods
Precision cylindrical optical rods manufactured with custom diameter, length, polishing and coatings.
Function: Light Guiding, Homogenization and Optical Transmission
Applications: Laser Systems / Illumination / Optical Instruments
Custom Optical Assemblies
Optical components integrated with mounts, spacers and housings through controlled assembly and alignment.
Function: Integrated Optical Functions According to Customer Drawings
Applications: OEM Equipment / Sensors / Precision Instruments
Custom Optical Component Comparison
Reference guide for custom optical components and assemblies based on materials, function and application.
| Product Type | Typical Materials / Components | Primary Function | Typical Applications |
|---|---|---|---|
| Optical Windows | Optical Glass / Fused Silica / IR Materials | Optical Transmission and Environmental Protection | Imaging / Sensors / Laser Systems |
| Optical Lenses | Optical Glass / Fused Silica / IR Materials | Focusing, Collimation and Image Formation | Imaging / Laser Systems / Optical Instruments |
| Optical Prisms | Optical Glass / Fused Silica | Beam Deviation, Image Orientation and Path Folding | Imaging / Measurement / Laser Systems |
| Optical Filters | Optical Glass / Fused Silica / Filter Substrates | Spectral Selection, Attenuation and Wavelength Control | Machine Vision / Imaging / Spectroscopy |
| Optical Mirrors | Glass / Metal Substrates + Reflective Coatings | Reflection, Beam Steering and Optical Path Control | Laser Systems / Imaging / Scientific Instruments |
| Optical Domes | Sapphire / Fused Silica / IR Materials | Optical Transmission and Sensor Protection | EO-IR Sensors / Thermal Imaging / Harsh Environments |
| Optical Rods | Optical Glass / Fused Silica / Crystal Materials | Light Guiding, Homogenization and Optical Transmission | Laser Systems / Illumination / Optical Instruments |
| Optical Assemblies | Lenses / Windows / Prisms / Mirrors / Filters + Housings | Integrated Optical Functions According to Customer Drawings | OEM Equipment / Sensors / Precision Instruments |
Typical Custom Manufacturing Capabilities
Typical capabilities are shown below. Final tolerances depend on material, geometry, size, quantity and inspection method and are confirmed during drawing review.
| Specification | Typical Capability / Options | Quotation Notes |
|---|---|---|
| Supported Component Types | Custom optical windows, lenses, prisms, filters, mirrors, domes, rods and optical assemblies | Provide component type, optical function and drawing |
| Supported Materials | Optical glass, fused silica, sapphire, CaF₂, BaF₂, silicon, germanium, ZnSe, ZnS and other drawing-specified optical materials | Selection is reviewed against wavelength, environment, geometry and cost |
| Diameter and Thickness Ranges | Custom and drawing-defined; capability varies by material, component type, aspect ratio and geometry | State diameter or length × width, thickness and tolerances |
| Surface Quality | Typically 60-40, 40-20, 20-10 or laser-grade 10-5 scratch-dig, depending on material and application | Specify standard, cosmetic zones and coated-surface requirements |
| Surface Flatness / Figure | Drawing-defined flatness, irregularity or curved surface figure | Specify test wavelength, clear aperture and reference condition |
| Dimensional Tolerances | Standard to precision tolerances for diameter, thickness, length, width, angles, radii and mechanical features | Final values are confirmed by DFM review |
| Centration and Parallelism | Custom centration for lenses and curved optics; custom wedge or parallelism for windows, filters and plane-parallel parts | Define datum, units, clear aperture and inspection method |
| Optical Coating Options | AR, BBAR, HR, beam-splitter, filter, aluminum, silver, gold, dielectric and DLC coatings from UV through infrared | Provide wavelength, AOI, polarization, performance target, laser power and environment |
| Prototype Production | Engineering samples and low-volume prototypes for design verification and system testing | Inspection scope is agreed before production |
| Volume Production | Small-batch, repeat-order and OEM volume manufacturing against an approved drawing and process | Provide annual demand, lot size and delivery schedule |
| Inspection Reports | Dimensional, cosmetic, surface figure, centration, parallelism and coating-performance records available as required | Specify report format, sampling plan and certificates at quotation |
| Custom Specifications | Material, geometry, dimensions, radii, focal length, angles, surface requirements, coating, assembly, alignment, packaging and acceptance criteria | Subject to drawing and manufacturability review |
Drawing Review to Production
A structured process aligns the optical specification, manufacturing route, inspection plan and production quantity.
1. Drawing Review
Material, geometry, dimensions, datums, optical tolerances, coating, wavelength and acceptance criteria are reviewed before quotation.
2. DFM & Quotation
Manufacturability, inspection, lead time, quantity and cost drivers are evaluated, with proposed tolerance adjustments identified.
3. Prototype Production
Engineering samples or a pilot lot can be produced for dimensional, optical and system verification.
4. Volume Production
Controlled processes support small-batch, repeat-order and OEM production against the released drawing.
5. Inspection & Reports
Dimensional, surface, centration, parallelism and coating reports can be supplied when specified with the order.
Custom Optical Component Manufacturing Capability
Optical component manufacturing, coating, mounting, bonding, alignment and inspection are controlled according to customer drawings.
Optical Component Manufacturing
Precision manufacturing of custom windows, lenses, prisms, filters, mirrors, domes, rods and assembly components according to approved customer drawings.
Precision Polishing & Coating
Controlled surface generation and polishing, followed by AR, BBAR, HR, metallic, dielectric, filter or infrared coatings according to wavelength requirements.
Precision Assembly
Controlled mounting, bonding, spacing and mechanical integration of optical and structural components.
Optical Alignment
Assembly and alignment of optical elements according to system axis, spacing and orientation requirements.
Quality Inspection
Dimensional, cosmetic and optical inspection of components and completed assemblies before shipment.
Why Choose Chenyu Optics for Custom Optical Components
Chenyu Optics supports both optical component manufacturing and assembly integration, allowing customers to source finished optical subassemblies instead of managing multiple individual component suppliers.
Applications of Custom Optical Components
Laser Systems
Precision optical assemblies for beam focusing, collimation, steering and laser delivery systems.
Machine Vision
Lens, filter and window assemblies for industrial cameras and automated inspection equipment.
Optical Sensors
Integrated optical components for sensing, detection and measurement modules.
Medical and Scientific Instruments
Precision optical assemblies for analytical, laboratory and imaging equipment.
Infrared Imaging
Infrared lens and window assemblies for thermal cameras and IR sensor modules.
OEM Optical Equipment
Custom optical subassemblies manufactured according to customer mechanical and optical system designs.
Custom Optical Components FAQ
What types of optical components can be integrated into an assembly?
Lenses, windows, prisms, mirrors, filters and infrared optical components can be combined with mechanical housings, spacers and retaining structures.
Can you manufacture optical assemblies according to customer drawings?
Yes. Chenyu Optics supports drawing-based manufacturing and assembly, including optical components, mechanical interfaces, coatings and inspection requirements.
Can you manufacture both the optical components and the assembly?
Yes. Optical components can be manufactured, coated and assembled according to project requirements, reducing the need for customers to manage multiple suppliers.
What bonding and mounting options are available?
Options include optical adhesive bonding, mechanical retention, spacers, threaded housings and custom mounting structures depending on the assembly design.
Can you perform optical alignment and inspection?
Yes. Alignment, dimensional inspection and optical verification can be performed according to assembly requirements and customer-defined specifications.
How can I request a quotation for a custom optical assembly?
For a quotation, send your 2D drawing and available STEP/IGES model, component type, material, dimensions and tolerances, surface quality, flatness or surface figure, centration or parallelism, coating wavelength, AOI, polarization, environment, inspection-report needs, prototype quantity and expected production volume through the contact page.
Need Custom Optical Components?
Send your drawing, material, dimensions, optical tolerances, coating band, inspection requirements, prototype quantity and expected volume. Chenyu Optics supports drawing review, custom manufacturing, coating, assembly, inspection and repeat OEM production.
