Plano Concave Cylindrical Lens
Plano Concave Cylindrical Lenses are precision optical components with one flat surface and one cylindrical concave surface, designed to provide negative focal length and control light divergence along a single axis. Unlike spherical lenses that affect light in two dimensions, cylindrical lenses provide one-dimensional beam expansion or focusing. Chenyu Optics manufactures plano concave cylindrical lenses in BK7, fused silica and UV fused silica, uncoated or with UV AR, VIS AR and NIR AR coatings.
Plano Concave Cylindrical Lens Overview
Plano Concave Cylindrical Lenses are precision optical components with one flat surface and one cylindrical concave surface, designed to provide negative focal length and control light divergence along a single axis.
Unlike spherical lenses that affect light in two dimensions, cylindrical lenses provide one-dimensional beam expansion or focusing. They are widely used in laser beam shaping, line generation, optical scanning, imaging systems and machine vision applications.
Chenyu Optics supports custom plano concave cylindrical lens manufacturing according to customer drawings, including custom diameter, focal length, cylindrical radius and coating design for prototype and repeat production.
Key Advantages of Plano Concave Cylindrical Lens
Laser Line Generation & Beam Shaping
Plano concave cylindrical lenses are widely used for one-axis beam divergence control in laser beam shaping systems, line generation setups and optical scanning equipment.
Typical Specifications of Plano Concave Cylindrical Lens
| Material Options | BK7, Fused Silica, UV Fused Silica |
|---|---|
| Optical Function | One-dimensional beam expansion / Divergence control |
| Lens Type | Plano concave cylindrical lens |
| Focal Length | Customized |
| Cylindrical Radius | Customized |
| Transmission | High optical transmission |
| Surface Accuracy | λ/4 – λ/10 @ 633 nm |
| Surface Quality | 20-10 / 40-20 scratch-dig |
Lens Geometry & Optical Principle
Why Choose Chenyu Optics for Plano Concave Cylindrical Lens
Chenyu Optics focuses on drawing-based precision lens manufacturing for laser, imaging and scanning optical systems. We support prototype verification, small-batch production and repeat manufacturing for non-standard plano concave cylindrical lenses.
Manufacturing Capability for Plano Concave Cylindrical Lens
Precision Cylindrical Machining
Accurate cylindrical surface processing to achieve precise one-axis beam control and stable optical performance.
Optical Coating
UV AR, VIS AR and NIR AR coating options for laser, imaging and scanning applications.
Inspection & Packaging
Dimensional inspection, cylindrical surface review, optical performance checking and protective packaging before shipment.
Custom Manufacturing Options for Plano Concave Cylindrical Lens
Dimensions & Focal Length
Custom diameter, focal length and cylindrical radius can be manufactured according to customer drawings and optical design requirements.
Surface & Optical Quality
Surface accuracy and surface quality can be selected according to beam shaping and imaging performance requirements.
Coating & Wavelength Design
Uncoated, UV AR, VIS AR, NIR AR and custom AR coatings can be specified for laser, imaging or scanning applications.
Cylindrical vs. Spherical Lens Comparison
| Plano Concave Cylindrical | Plano Concave (Spherical) | Double Concave | Negative Meniscus | |
|---|---|---|---|---|
| Axis Symmetry | Single-axis power only | Rotationally symmetric | Rotationally symmetric | Rotationally symmetric |
| Surface Configuration | One flat, one cylindrical concave surface | One flat, one concave surface | Two concave surfaces | One concave, one convex surface |
| Typical Function | One-dimensional beam expansion, line generation | Beam divergence, single-surface aberration control | Strong, symmetrical beam divergence | Beam divergence with reduced spherical aberration |
| Typical Applications | Laser line generation, beam shaping, scanning | Laser beam expansion, collimation systems | Laser beam expansion, divergence control | Precision beam divergence, aberration-sensitive systems |
Applications of Plano Concave Cylindrical Lens
Laser Beam Shaping Systems
One-axis beam shaping for laser optical systems.
Laser Line Generation
Precision line generation for laser applications.
One-Dimensional Beam Expansion
Single-axis beam expansion for optical systems.
Optical Scanning Systems
Beam shaping for optical scanning applications.
Machine Vision Systems
Line generation and beam shaping for industrial inspection.
Barcode Scanning Equipment
Precision line generation for barcode reading optics.
Plano Concave Cylindrical Lens FAQ
What is the function of a plano concave cylindrical lens?
A plano concave cylindrical lens diverges light along one axis and is used for one-dimensional beam expansion or shaping.
What is the difference between a cylindrical lens and a spherical lens?
A cylindrical lens controls light in one axis, while a spherical lens affects both horizontal and vertical directions.
Can plano concave cylindrical lenses be used for laser applications?
Yes. They are commonly used for laser line generation, beam shaping, and scanning systems.
Can focal length and cylindrical curvature be customized?
Yes. Chenyu Optics provides customized focal lengths, cylindrical radii, dimensions, materials, and AR coatings.
What information should I provide for a quotation?
Please provide diameter, focal length, cylindrical radius, surface accuracy, surface quality, coating requirement, quantity and drawing if available.
Where can I learn more about lens design?
Additional information on lens design can be found from Edmund Optics.
Related Products for Plano Concave Cylindrical Lens
Need Custom Plano Concave Cylindrical Lenses?
Send us your drawing, focal length, cylindrical radius, diameter, coating requirements and quantity. Chenyu Optics will review the optical and mechanical specifications and provide a suitable plano concave cylindrical lens manufacturing suggestion.
