Dispersion Prisms
- Ray Deviation of 60° If Coated
- Ideal as a Dispersion Prism if Uncoated
- Right Handed Image
Dispersion prisms are optical components designed to separate light into its constituent colors by exploiting the different refractive indices of wavelengths. Commonly used in spectroscopy and laser systems, these prisms enable precise light dispersion for various applications. Available in materials like BK7 and fused silica, dispersion prisms provide high performance in both research and industrial environments.
General Specification
| Dimensional Tolerance (mm): | ±0.13 |
| Bevel: | Protective bevel as needed |
| Substrate: | N-BK7 |
| Surface Quality: | 80-50 |
| Angle Tolerance (arcmin): | ±10 |
| Image Orientation: | Right-Handed |
| Ray Deviation (°): | 60 |
| Power (fringes) @ 632.8nm: | 3 |
| Irregularity (fringes) @ 632.8nm: | 1 |
