Custom Silicon Optical Windows
- Designed for 1.2 to 7 µm NIR and MWIR applications
- Ideal for weight-sensitive applications
- 3.More robust and less fragile than Germanium or ZnSe windows
Custom Silicon Optical Windows are high-precision infrared optical components, ideal for applications in thermal imaging, IR sensors, and laser systems. Silicon (Si) windows offer excellent transmission in the 1.2–8μm wavelength range, high durability, and low density, making them perfect for lightweight optical systems. We provide customized Si windows with superior surface quality, tight tolerance, and AR coatings to meet specific requirements. Contact us for high-performance Custom Silicon Optical Windows tailored to your needs.
General special
| Dimensions: | Diameters 5mm to 200mm Squares/Rectangles: 5mm to 140mm |
| Squares/Rectangles: 5mm to 140mm | |
| Thickness Range: | 0.5mm to 25mm (subject to dimension) |
| Edge Finish: | Ground or polished |
| Surface Quality: | 80/50 to 20/10 scratch/Dig |
| Parallelism: | Up to 1 arc minute |
| Material Options: | Float zone N or P type; purity > 6N, orientations <100> or <111>, resistivity >100 ohm, uncoated 55-57% @3-5 microns, Polycrystalline, Monocrystalline & EMI grade lower resistivity |
| Coating Options: | AR coatings from 1-8 microns & bandpass coatings |
| Options: | Drilled holes, shapes, wedges, squares & rectangles |
| Orientation: | 100 |
