What is a Half-Penta Prism?

A Half-Penta Prism is a type of optical prism designed to deviate light by exactly 90° while maintaining the image orientation.

The prism offers a compact design that is often used when space is limited but precise beam deflection is required.

People also call it a semi penta prism or Bauernfeind prism.

Features of Half-Penta Prisms



• Precise 90° Beam Deflection: It provides accurate light deflection without inverting or reversing the image.
• High Optical Quality: Made from high-quality optical glass such as N-BK7, fused silica, or custom materials, ensuring minimal light loss and distortion.
• Customizable Tolerances: Available in various sizes and tolerances, suitable for precision optical instruments.
• Compact Design: Ideal for setups with limited space, allowing optical systems to maintain performance without increasing footprint



Structure of the prism



A half penta prism is shaped like a penta prism cut in half.

It will have four lateral sides, two of which are transparent.

The main substrates include BK7 Glass, Fused Silica and other materials.

Also, the  entrance and exit face can choose anti-reflective or protective coatings.



Applications of Half-Penta Prism



• Laser Systems:

Steering and folding laser beams in precision optical setups.

• Surveying Instruments:

In total stations and theodolites for accurate angle measurements.

• Imaging Systems:

The prism maintains image orientation while redirecting light paths in cameras and microscopes.

• Scientific Research:

Deployed in laboratories requiring high-precision beam manipulation.

• Optical Alignment:

It helps in aligning optical components in complex optical systems.



Our experienced design team provides customers with support for optical system design, ranging from the initial design stage to prototype development and production.

The customization options may include specific coating wavelengths or other requirements to meet the unique needs of the customer’s application.

If you are interested, please contact us or view or other prism products.
