Fused Silica Window
- Broad Transmission Range from 200 – 3500nm
- λ/10 Transmitted Wavefront Distortion
- Excellent Thermal Stability
- custom-made
High-Precision Fused Silica Windows | Custom Optical Solutions
Fused silica windows offer exceptional optical clarity, high transmission, and superior thermal and chemical resistance. Ideal for high-power laser systems, UV applications, and precision optics, our custom-made fused silica windows ensure minimal wavefront distortion and excellent durability.
We provide custom sizes, coatings, and edge treatments to meet your specific requirements. Contact us today for high-quality fused silica windows tailored to your optical applications!
General specifications
| Diameter | 0.2-300mm |
| Thickness | 0.1-30mm or Custom |
| Diameter Tolerance | +/-0.02mm |
| Surface quality (scratch & dig) | 20/10 or better |
| Clear aperture | >85%, >90% |
| Surface accuracy | λ/10 |
| Parallelism | <30 arc sec |
| Bevel | 0.1~0.3mm x 45 degree |
| Coating | AR, BBAR or Custom |
